LONGSE NVR Καταγραφικό , 4K, H.265/H.264, 32 Κανάλια

Περιγραφή

LONGSE NVR Καταγραφικό , 4K, H.265/H.264, 32 Κανάλια

Τεχνικά χαρακτηριστικά
System
Main Processor: Quad Cortex A53
Operating System: Embedded LINUX
Video
Input: 32CH (4000x3000, 3840x2160, 2592x1944, 2048x1536, 1920x1080, 1280x960, 1280x720, etc)
Output: 1 VGA, 1 HD
Audio
Input: 1 Port RCA, support 32CH IPC audio input
Output: 1 Port RCA(Linear, 1kΩ), HD output
Audio Bit Rate: 64kbps
Audio Compression standard: G711u, G711a, AAC
Intercom: support (two-way)
Alarm
Sensor Input: 4CH
Output: 1CH
Motion Detection: 32 Channel, MD Zones: 396 (22 x 18)
Trigger Events: Recording, Email, FTP, Snapshot, Buzzer and Screen Tips
Record Rate:
-PAL: 12MP @32CHx25fps,8MP @32CHx25fps,5MP @32CHx25fpss, 4MP @32CHx25fps, 3MP @32CHx25fps, 1080P @32CHx25fps, 960P @32CHx25fps, 720P @32CHx25fps, D1 @32CHx25fps
-NTSC: 12MP @32CHx30fps, 8MP @32CHx30fps, 5MP @32CHx30fps, 4MP @32CHx30fps, 3MP @32CHx30fps, 1080P @32CHx30fps, 960P @32CHx30fps, 720P @32CHx30fps, D1 @32CHx30fps
Record Mode: ManualTimerMotion DetectionSmart Event
Playback & Backup
Local Sync Playback: 2CH 12MP @30fps, 4CH 8MP @30fps, 6CH 5MP @30fps, 8CH 4MP @30fps, 16CH 1080P @30fps, 16CH 960P @30fps, 16CH 720P @30fps, 16CH D1 @30f
Decode Capability: 1080P(1920x1080) @480fps
Remote Sync Playback: YES
Search Mode: ALL, Timing Video, Motion Detection, Alarm,Tag search, Smart Event, Pictrue, Log
Playback Functions: Play, pause, fast forward, rewind, previous frame, next frame, electronic zoom, clip, audio
Backup Mode: USB Device/Network
Περιεχόμενα συσκευασίας
NVR καταγραφικό
Ενσύρματο ποντίκι
Αντάπτορας τροφοδοσίας
Καλώδιο τροφοδοσίας
2x καλώδια SATA
Βίδες
Εγχειρίδιο χρήσης
